Radio Direction Finding – 1992 IRMA CSTI-1000

I worked for a local start up back in 1992 as Chief Engineer – Hardware and this is what we came up with. It started with some patents and technology transfer with the Department of Communication (Federal Government).

All radios were from the local ham supplier and a Single Board Computer (check out the specs for a good laugh) from a supplier in the back of Circuit Cellar Magazine.

Everything was pretty much COTS except for the controller board. It worked well and we had the initial Proof of Concept in Mexico. We placed these on 3 hilltops and had some great success with radio direction finding.

We also used the Traffic Study or Channel Occupancy tool which helped provide insights in signal occupancy.

Now, I am “full circle” and engaged once again in a project but its now SDR, MP3, WiLAN and message bus technology.

I spent a whole day doing up the photography for the brochure which to this day I still recall how many packs of Polaroids I went through. I also used the Instant 35mm film for proofing. Today, I could just use my Smartphone.

A typical use case would be where the radio inspector would have interference complaints. He could get the location, an audio recording with freq, time and date stamp and even activate the radio and inform the interfering station over the air that he is under investigation.

Another popular example was to track channel usage and apply that to the current spectrum management policies.

As old school as it is the IRMA would actually still work today as an effective tool.

The receiver was the Icom 7000 and yes the modem was 2400 baud.  The Discone was the AH-7000 as a switched alternate.

irma1

irma2
